產生全符號網絡函數的Coates流圖法
COATES GRAPH APPROACH FOR GENERATING SYMBOLIC NETWORK FUNCTION
-
摘要: 本文引入符號碼數組、常數數組和記數數組,前二數組用來描述增廣矩陣的元素表達式,建立節點導納方程,后一數組用來寫出入度矩陣,然后根據入度矩陣產生Coates流圖的全部1-因子增益。在展開行列式時利用符號代碼合并同類項,消去相消項,從而得到無相消項的全符號網絡函數。Abstract: Symbolic code matrix, constant matrix and count matrix are defined. The first two matrixes are used to describe the elemental expressions of augmentation matrix and the node admittance equation is thus obtained. The third matrix is used to obtain the incoming degree matrix, and all the 1-factor gains of the coates graph are given according to the matrix. Using the code data, the determinant is expanded and all the same items in the expansion are merged. Thus the symbolic network function in which no term concellation occurs is generated.
-
P. M. Lin, G. E. Alderson, SNAP-A Computer Program for Generating Symbolic Nework Function, School Elec. Eng., Purdue Univ., Lafaytte, Ind., Rep. TR-EE70-16, Aug. 1970.[2]張惠廉,莊鎮泉,電子線路的計算機輔助設計,人民教育出版社,1979,下冊,244-259.[3]W. K. Chen, Applied Graph Theory, North-Holland, 1976, p. 144.[4]P. R. Adby, Applied Circuit Theory, Matrix and Computer Methods, Ellis Horwod Limited, 1980, Chap.4.[5]陳樹柏,左愷,張良震, 網絡圖論及其應用,科學出版社,1982,第5章. -
