同一平面縫陣天線實現寬窄兩種波束的方法和饋電網絡
METHODS OF REALIZING WIDE AND NARROW DUAL BEAMS ON ONE PLANAR SLOT ARRAY AND FEED NETWORKS
-
摘要: 本文提出了同一平面縫陣天線實現寬窄兩種波束并能進行轉換的方法。進行了理論分析,給出了饋電網絡各參數之間的關系,對波瓣圖進行了計算,理論和實驗結果基本一致,該方法已在實際中使用。
-
關鍵詞:
- 縫陣天線; 平面縫陣天線; 天線饋電網絡
Abstract: The methods to realize wide and narrow beams by one planar slot array and feed networks are proposed, in which the theoretical analysis and the relations between parameters of feed networks are given. Theoretical results agree with the experimental data quite well. This methods has been applied in practice. -
W.L.Teeter, K. R. Bushore, IRE Trans. on MTT, MTT-5(1957), 225.[2]趙連貴,秦允錦,圓口徑單脈沖平面縫陣天線,空軍第一研究所內部資料.[3]L. F. Deerkoski, et al., U. S. Patent, 3,965,475. -
