屏蔽平面?zhèn)鬏斁€的色散特性分析
ANALYSIS OF DISPERSION CHARACTERISTICS OF SHIELDED PLANAR TRANSMISSION LINES
-
摘要: 本文利用橫向諧振法結合變分技術分析了屏蔽平面?zhèn)鬏斁€的色散特性。在傳輸線波的傳播方向,橫向放置兩個假想的理想短路面,構造諧振腔。根據橫向諧振條件,建立了傳輸線的傳播常數與諧振狀態下的短路面之間距離的關系。應用諧振腔的變分公式,導出了確定短路面之間距離的特征方程。作為示例,數值計算了鰭線的色散特性,結果與相應文獻中的數據相吻合。
-
關鍵詞:
- 微波技術; 平面?zhèn)鬏斁€; 色散特性; 諧振腔
Abstract: The dispersion characteristics of the shielded planar transmission lines are analyzed by the transverse resonance method combining with variational technique. Two shorting planes are transversely inserted in the propagation direction so as to form a closed resonator. The dominant mode propagation constant of a transmission line is related to the distance be-tween shorting planes through the resonant condition. The characteristics equation for the distance is derived by using the variational formulation for a generalized resonator. The numerical results for the finlines are given. A comparision is made with available data in literatures. -
L. P. Schmidt, et al., IEEE Trans. on MTT, MTT-28(1980), 981-985.[2]A.S.Omer, et al., IEEE Trans. on MTT, MTT-32(1984), 1626-1631.[3]戎敖生,李嗣范,中國科學(A輯),1987年,第11期,第1175-1183頁.[4]L.P.Schmidt, et al., IEEE Trans. on MTT, MTT-29(1981), 352-355.[5]R.Sotrentino, et al.,IEEE Trans.on MTT, MTT-32(1984),1633-1638.[6]R. F. Harrington, Time-Harmonic Electromgnetic Fields, New York, McGraw-Hill, 1961.[7]Rong Aosheng, Li Sifan, 12th Int. Infrared and Millimeter Waves Conf, Digest, U. S. A. 1987, pp.286-287. -
