Thompson-FDTD方法中的兩步法
TWO-STEP S THOMPSON-FDTD METHOD
-
摘要: 本文將流體力學領域的微分-Thompson變換與時域有限差分(FDTD)技術結合起來,所形成的Thompson-FDTD方法,首次用來計算和分析任意形狀介質體的電磁散射特性。該方法至少具有兩個明顯的優點:可以把不規則形體變換成規則形體,有利于精確匹配邊界條件;可以任意調配網格分布,有利于提高計算精度。其數值實現進一步證實了該方法能精確模擬任意形狀介質目標的電磁散射過程。
-
關鍵詞:
- Thompson變換; 時域有限差分; 任意形狀介質; 電磁散射
Abstract: This paper combines the differential-Thompson transformation involved in hydromechanics with the finite difference time domain (FDTD) technique to form Thompson-FDTD method. This method is applied by the first time to calculate the electromagnetic scattering properties of arbitrarily shaped dielectric objects. This method has at least two obvious advantages: It can transform arbitrary shaped bodies into regular structures and thus the boundary conditions are matched accurately; it can willfully dispose the grid distribution and thus better numerical accuracy is achieved. The numerical simulation further confirms its validity. -
Yee K S. Numerical solution of initial boundary value problems involving Maxwells equations in isotropic media. IEEE Trans.on AP, 1966, AP-14(3): 302-307.[2]Fusco M. FDTD algorithm in curvilinear coordinates. IEEE Trans.on AP, 1990, AP-38(1): 76-89.[3]Chen J S, Yee K S, et al. Conformal FD-TD with overlap grids，IEEE Trans. on AP, 1992, AP-40(9): 1068-1075.[4]Zivanovic S S, Yee K S, Mei K K. A subgridding method for the finite difference-time domain method to solve Maxwells equations. IEEE Trans.on MTT, 1991, MTT-39(3): 471-479.[5]Thames F C, Thompson J F, et al. Numerical solution for viscous and potential flow about arbitrary two-dimensional bodies using body-fitted coordinates system[J].J. Comp.Phys.1977, 24:245-273[6]Liao C, Zhao Y, tin W. New method for numerical solution of Maxwells equations. Electron. Lett. 1995, 31(4): 261-262.[7]廖成,任朗.Thompson變換-FDTD方法模擬不規則形體的電磁散射間題.西南交通大學學報,1996, 31(3): 318-322.[8]Liso C, Jen L. Numerical solution for EM scattering about arbitrary two-dimensional bodies with the use of the Thompson-FDTD method[J].Microwave and Opt. Tech. Lett.1996, 13(4):233-2363.0.CO;2-9' target='_blank'>[9]Bayliss A, Turkel E. Radiation boundary condition for wave-like equations[J].Commun. Pure Appl .Math.1980, 33:707-725 -
