封閉介質波導分析多模網絡方法
ANALYSIS OF CLOSED DIELECTRIC WAVEGUIDEMULTIMODE NETWORK APPROACH
-
摘要: 本文將多模網絡理論的積木式分析方法和嚴格的場匹配技術相結合,對一大類封閉介質波導的色散特性進行了研究。用所述方法給出了若干波導結構的數值例子,為了比較,也用有限元法和EDC法對同一結構進行了計算。結果表明,本文方法具有與有限元方法同樣的精度,又能保持EDC方法的簡便特性,從而證實了所述方法的效能。Abstract: The dispersion characteristics of a class of closed dielectric waveguide areinvestigated by the method which combines the building-block approach of multimode network theory with rigorous mode matching procedure. Several numerical examples for different guiding structures have been given by the approach. The same structures are also analyzed with the finite element method and the EDC method for comparison. The calculations show that the present approach yields as highly accurate results as the finite element method while almost retaining the simplicity of the EDC method, and justify the utility of the present method.
-
C. T. Lin, IEEE Trans. on MTT, MTT-29(1981), 805-810.[2]徐善駕,應用科學學報,1(1983)2, 135-141.[3]徐善駕,通信學報,4(1983)3, 8-14.[4]Xu Shanjia, Journal of Electronics (China), 2(1985), 30-39.[5]M. V. Mclevige, T. Itoh, R. Mittra, IEEE Trans on MTT, MTT-23(1975), 788-794.[6]S.T.Peng, A. A. Oliner, IEEE Trans. on MTT, MTT-29(1981), 843-855.[7]E .A.J. Marcatili, Bell Sys. Tech. J., 48(1969) 9, 2071-2102. -
