通用硬件模糊控制器研究
On the hardware realization of general fuzzy controller
-
摘要: 提出了一種基于多值邏輯電路的模糊控制器硬件實現方案,采用規則分時進行硬件模糊推理,不同規則的推理結果合并后形成模糊輸出,經模糊判決后形成精確量輸出。該方案的復雜性不受規則數量的影響,執行速度不受語言變量維數的影響,該方案通過改變存儲器數據可以方便地調整隸屬度函數和模糊控制規則,克服了硬件模糊控制器靈活性差這一重大缺陷,該方案便于以VLSI實現。
-
關鍵詞:
- 多值邏輯; 特征展開近似推理; 模糊控制器
Abstract: A new hardware realization methodology of fuzzy controller based on Multiple-Valued Logic (MVL) circuits is proposed. To the methodology, the hardware fuzzy inference process for different rule is executed in different time. The combination of the inference results of different rules makes fuzzy output, then it is changed to general output by defuzzification. According to this methodology, the complexity of the controller is free from the number of rules and the executive speed free from the dimension of fuzzy variables, furthermore, the choice of membership functions is free and the adjustment of fuzzy control rules is easy. The new methodology can be easily realized by using the very-large-scale-integration technique. -
馮宏娟,等,直接修改控制規則的自調整模糊控制器,電子學報,1992,20(2),10-16.[2]王守臣,等,基于多值邏輯電路和二值PLA的硬件模糊控制器,電子學報,1998,26(8),86-88.[3]何平,等,模糊控制器的設計及應用,北京,科學出版社,1997,155 181,104[4]Zheng Tang,et al.,Alearning multiple-valuedlogic networks:algebra,algorithm and applications,IEEE Trans.on Computers,1998,47(2),247-251.[5]徐德,等,截斷斜坡函數多值邏輯神經元,微電子學,2000,30(2),83-87.[6]諸靜,等,模糊控制原理與應用,北京,機械工業出版社,1995,128. -
