基于Hemite外推的多柱體時頻域電磁散射計算
Calculation of electromagnetic scattering of multi-cylinders in time and frequency domains based on hermite extrapolation
-
摘要: 首先根據散射體在高斯脈沖平面波激勵下感應電流的能量幾乎全部集中在時間軸和頻率軸上的有限范圍內,該文將時域響應展開為系數待定的連帶Hermite級數的疊加,并根據連帶Hermite函數的傅里葉變換的自反性,得到與時域響應形式類似的頻域響應;然后利用時域方法和頻域方法分別計算散射體上感應電流的早時響應和低頻信息;最后經過時域和頻域聯合外推計算,由早時響應和低頻信息確定時域和頻域響應的待定系數,從而獲得了整個時域和頻域的完全響應。該文用這種外推方法分析計算了多導體柱的電磁散射。Abstract: The time-domain response of the induced currents on a scattering object irradiated by a plane wave with a Gaussian pulse in time is expanded as an associate Hermite series in this paper. Using the isomorphism of the associate Hermite function and its Fourier transform, the frequency-domain information can be obtained similarly to the time-domain expansion. According to the corresponding relation between time-domain analysis and frequency-domain analysis, and using the early-time response and the low-frequency information of the induced currents, the non-known coefficients in the expansion series can be decided. The entire responses of the induced currents on the scattering object in both time and frequency domains can be obtained at one time by simultaneous extrapolation computation using both the early-time response and the low-frequency information of the induced currents. Electromagnetic scattering of multi-cylinders are calculated and analyzed based on this extrapolation methodology in this paper.
-
R.F.Harrington著,計算電磁場的矩量法,王爾杰等譯,北京,國防工業出版社,1981,49-72.[2]C.J. Reddy, M. D. Deshpande, et al., Fast RCS computation over a frequency band using methodof moments in conjunction with asymptotic waveform evaluation technique, IEEE Trans. on AP,1998, 46(8), 1229-1233.[3]C.M. Tong, J. Liang, W. Hong, A fast frequency sweeping method for RCS computation basedon AWE technique, 2000 China-Japan Joint Meeting on Microwaves, Nanjing, China. 234-237.[4]S.M. Rao, Time Domain Electromagnetics, San Diego, USA, Academic Press, 1999, 131-150.[5]彭仲秋,瞬變電磁場,北京,高等教育出版社,1989,1-11.[6]R.S. Adve, T. K. Sarkar, Q. M. Pereira-Filho, S. M. Rao, Extrapolation of time-domain responsesfrom three dimensional conducting objects utilizing the matrix pencil techniques, IEEE Trans.on AP, 1997, 45(1), 147-156.[7]R.S. Adve, T. K. Sarkar, Simultaneous time- and frequency-domain extrapolation, IEEE Trans.on AP, 1998, 46(4), 484-493.[8]M.M. Rao, T. K. Sarkar, T. Anjali, R. S. Adve, Simultaneous extrapolation in time and frequencydomains using Hermite expansion, IEEE Trans. on AP, 1999, 47(6), 1108-1115.[9]H.J.Weaver著,離散和連續傅里葉分析理論,王中德,張輝譯,北京,北京郵電學院出版社,1991,216-219. -
