熱激勵硅梁諧振器研究
STUDY OF THERMALLY EXCITED SILICON BEAM RESONATOR
-
摘要: 作者利用微電子機械加工技術成功研制出用于高精度壓力傳感器的硅梁諧振器。采用熱激勵方式,測定了諧振梁的開環振動幅頻特性:室溫真空中諧振峰-3dB帶寬1.2Hz,Q值大于33000。從理論和實驗兩方面討論了低熱激勵功率條件下激勵功率與諧振頻率的線性關系,二者符合較好。
-
關鍵詞:
- 熱激勵; 硅梁; 諧振器
Abstract: A micro-machined single crystal beam resonator for high accuracy pressure sensors by utilizing Micro-ElectroMechanical System (MEMS) technology has been successfully fabricated. By means of thermal excitation, the frequency response (including amplitude and phase) of the resonator has been characterized with an open-loop frequency sweeping method. The -3dB width of resonant peak (less than 1.2Hz) corresponds a very high quality factor Q value greater than 33000 in vacuum at room-temperature. The frequency response of the resonator at different levels of excitation has been discussed theoretically and experitrientally The result shows a good linearity of frequency versus excitation power at lower excitation power, and is coincident with the theory. -
J. C. Greenwood, D. W. Sat cheil, A miniature silicon resonant pressure sensor lEE Proc-l.l988, 135(5), 369-372.[2]J. Greenwood, T. Wray, High accuracy pressure measurement with a silicon resonant sensor.Sensors and Actuators, 1993, A37-38, 82 85.[3]K. Ikeda, H. Kuwayama, T. Kobayashi, T. Watanabe, T. Nishikawa, T. Toshida. K. Harada.Silicon pressure sensor int egrat, es resonant st rain gauge on diaphragm, Sensors and Actnators .1990, A21-23, 146-150.[4]T.S.J. Lanmerink, M. Elwenspoek, J. H. J. Fhitman, Performance of thermally excited reso-nantors, Sensors and Actuat ors, 1990, A21-23, 352-356.[5]徐芝綸編著,彈性力學(下),北京,高等教育出版社,1998,第13章,55-63. -
