雙漸變技術減小 AM-PM轉換系數的初步研究
AN INVESTIGATION INTO REDUCING AM-PM CONVERSION COEFFICIENT BY THE DOUBLE TAPER HELIX TECHNIQUE
-
摘要: 行波管欠壓工作能減小AM-PM轉換系數。因此在行波管中加入一段工作于該狀態的慢波線應能改善AM-PM轉換特性。由此引出了所謂雙漸變技術。 本文對該技術作了初步分析,實際制管證明了該技術不僅能提高電子效率,而且能改善AM-PM轉換特性。并且還具有多電平工作、降壓效果好等優點。本文還總結了一套小信號設計方法。
-
關鍵詞:
Abstract: The eonversion coefficient of a TWT can be reduced, when it works at under-voltage condition. Therefore if a section of helix which works at under-voltage condition is added to a TWT, the improvement of AM-PM eonversion coefficient can be expected,then a doubl taper helix technique is developed.This paper describes the double taper helix technique and presents a small signal design method. The actual TWT which uses the double taper helix proves that it not only raises the electron efficiency, but also improves the AM-PM conversion coefficient. Further experiment shows that this technique has other advantages, such as operation at two or three power levels and good depressed collector characteristics. -
周文表,過壓提高均勻螺距行波管效率的大信號計算,中國科學院電子學研究所內部報告,1979年.[5]周文表,電子學通訊,2(1980), 72. -
