具有跳耦結構的電流模式低通濾波器設計
DESIGN OF CURRENT-MODE LOW-PASS FILTER WITH LEAPFROG STRUCTURE
-
摘要: 本文討論了電流模式RC梯形結構低通濾波器的一種有源實現方法跳耦法,以此實現的電流模式低通濾波器采用CCⅡ,CCⅠ器件做為有源器件,比相應電壓模式電路結構簡單,且RC元件全部接地。這種跳耦結構和梯形結構一樣具有低的元件靈敏度。
-
關鍵詞:
- 濾波器; 梯形結構; 跳耦; CC器件
Abstract: Leapfrog technique is discussed and used to realize current-mode lowpass active RC ladder structure. The current-mode lowpass filter realized by this method only takes CCII, CCI as active devices, and all RC elements axe grounded, therefore, this structure is simpler than the relating voltage-mode one. It also has low sensitivity as the other ladder structures do. -
Pal k. Electron. Lett., 1981, 17(21): 807-808.[2]Senani R. Electron. Lett., 1982, 18(10): 413-414.[3]Higashimura M, FWcui Y. Int[J].J. Electron.1989, 66(4):633-638[4]Chun-Li Hou, Yan-Pei Wu,Fu-Chao Lu. Int[J].J. Electron.1993, 74(4):577-586[5]Chun-Li Hou, Rong-Da Chen, Yan-Pei Wu. Int[J].J. Electron.1993, 74(6):917-923[6]Pal K. Electron. Lett., 1980, 16(16); 639-641.[7]Nandi S, Java P B, Nandi R. Electron. Lett., 1983, 19(7): 251.[8]Senani R. Electron. Lett., 1984, 20(5): 205-206. -
