短相干積累條件下天波超視距雷達的艦船檢測
The Ship Detection of Sky Wave over-the-Horizon Radar with Short Coherent Integration Time
-
摘要: 天波超視距雷達(OTHR)的觀測范圍非常廣，實戰中經常要求在短相干積累條件下檢測出艦船目標。然而短相干積累時間帶來的低多普勒分辨率很難從強大的海雜波中區分出艦船。為了解決這一問題?？梢圆捎煤ｋs波循環對消法，這就要求對雜波參數進行精確估計。傳統方法直接利用Fourier譜中的最大幅度估計雜波參數，估計精度不高從而導致對消性能不太理想。該文提出了一種新的基于FFT相位分析的雜波對消法。該方法與傳統的雜波對消相比，有效提高了參數估計精度，減小了剩余雜波強度和擴散程度，有利于艦船目標的峰值顯露和從剩余雜波中區分出艦船。以上分析和比較得到了實測數據的檢驗。
-
關鍵詞:
- 天波超視距雷達; 艦船檢測; 海雜波循環對消
Abstract: Since the surveillance area of sky wave Over-The-Horizon Radar (OTHR) is very vast, realizing the ship detection with short coherent integration time (GIT) is an operational requirement for OTHR. However, short CIT and the resulting low Doppler resolution cannot separate the ship target from the close powerful ocean clutter. To resolve this problem, clutter cancellation algorithm can be adopted but it requires accurate estimation for clutter parameters, The conventional cancellation method only uses the maximal amplitude of Fourier transform to estimate the clutter parameters, which may not get satisfied estimation and cause imperfect clutter cancellation. In this paper, the phase information of Fourier transform is combined to provide more accurate estimation of clutter parameters. As the result, the power and spreading of clutter residue are reduced which is helpful for the ship visibility and identification. The above analysis and comparison have been demonstrated by real data. -
Root B T. HF over-the-horizon radar ship detection with short dwells using clutter cancellation[J].Radio Science.1998, 33(4):1095-1111[2]齊國清,賈欣樂.基于DFT相位的正弦波頻率和初相的高精度估計方法.電子學報,2001,29(9):1164-1167.[3]Crombie D D. Doppler spectrum of sea echo at 13[J].6Mc/s. Nature.1955, 175:681-682[4]Barrick D E. First-order theory and analysis of MF/HF/VHF scatter form the sea. IEEE Trans.on AP., 1972, AP-20(1)0: 2-10.[5]Parent J, Bourdillon A. A method to correct HF skywavc backscattcrcd signals for ionospheric frequency modulation. IEEE Trans. on AP., 1988, AP-36(1): 127-135.[6]Barnum J R. Ship detection with high-resolution HF skywave radar[J].IEEE J. of Oceanic Engineering.1986, 11(2):196-209[7]Anderson S J, Abramovich Y I. A unified approach to detection, classification, and correction of ionospheric distortion in HF sky wave radar systems[J].Radio Science.1998, 33(4):1055-1067[8]Anderson S J. Adaptive remote sensing with HF skywave radar. IEE Proc.-F, 1992, 139(2):182-192.[9]Olkin J A, Nowlin W C, Barnum J R. Detection of ships using OTH radar with short integration times. IEEE National Radar Conference, Syracuse, USA, 1997: 1-6.[10]Anderson S J, Mahoney A R, Turley M D E. Applications of superresolution techniques to HF radar sea echo analysis, Proceedings of the Pacific Ocean Remote Sensing Conference, Melbourue,Australia, 1994. -
