InP上Al膜的陽極氧化及其特性研究
STUDY OF THE ANODIZATION OF Al FILM ON InP SUBSTRATE AND ITS PROPERTIES
-
摘要: 本文報道了半導體InP上Al膜陽極氧化的研究,并用AES,V-V,DLTS和橢圓儀等測試方法研究了氧化膜的穩定性、電學特性、組分的縱向分布以及Al2O3/InP的界面特性,研究結果表明,陽極氧化Al2O3的介電常數為11～12,Al2O3/InP界面存在一個能量上連續分布的電子陷阱,DLTS峰值對應的能級位置約在Ec-Ec=0.5eV,其俘獲截面約為10-15cm2,Al2O3/InP的界面態密度為1011cm-2eV-1。陽極氧化Al2O3的穩定性要比InP自身氧化物好得多,更適于用作器件的鈍化保護和擴散掩蔽膜。
-
關鍵詞:
- 半導體界面; 陽極氧化; 介質薄膜
Abstract: The anodization of Al film on InP substrate and the properties of anodic Al2O3/lnP have been investigated by AES, DLTS, I-V, C-V and ellipsometer. The results show that the anodic oxide Al2O3 has the permitivity of 11-12 and the resistivity of 1.31013 ohm-cm. Interface state density at Al2O3/InP is about 1011cm-2eV-1. DLTS reveals that there is continuously-distributed interface electron traps at Al2O3/lnP interface. Anodic oxide Al2O3 exhibits good stability and electrical properties and could be used for passivation, diffusion mask and gate insulator etc. -
N. Susa et al., J. Electrocitem. Soc. 130(1983)11, 2220.[2]A. Yamamoto et al., J. Electrochem Soc, 129(1982)12, 2795.[3]H. H. Wiedet, J. Vac. Sci. Technol., 15(1978)4, 1498.[4]A. A. Studna et al.,Appl. Phys. Lett., 39(1981)12, 965.[5]D. H. Laughlin et al., Appl.Phys. Lett., 37(1980)10, 915.[6]Y. Hirayama et al., J. of Electronic Materials, 11(1982)6, 1011.[7]C: W. Wilmsen, Thin Solid Films, 39(1976)3, 105.[8]C. W. Wilmsen et al., J. Vac. Sci. Technol., 15(1978)4, 1513.[9]P. N. Favernec et al., Appl. Phys. Lett, 34(1978)9, 807.[10]K. Kamimura et al., Thin Solid Films, 56(1979)5, 215.[11]W. E. Spicer et al.,J. Vac. Sci. Teehnol, 17(198.0)5, 1019.[12]Y. Ohmachi et al., Japan J. Appl, Phys, 19(1980)7, 1425.[13]D. Fritzsche, Eleelron, Lets., 14(1978)3, 51.[14]K. Kanazawa et al., Japan J. Appl. Phys, 20(1981)3, L211. -
