寬邊側邊耦合四微帶傳輸線的頻率特性
FREQUENCY CHARACTERISTICS OF BROADSIDE EDGE-COUPLED MICROSTRIP LINES
-
摘要: 本文用譜域阻納分析法研究了普遍的多層介質寬邊側邊耦合多微帶線的頻率特性,給出了三層介質寬邊側邊耦合四微帶線的特性阻抗及等效介電常數的設計曲線。結果還表明該結構的偶-奇模特性阻抗Zeo隨頻率變化很大,當相對介電常數r較小時,變化更大。
-
關鍵詞:
- 微波技術; 耦合多微帶線; 譜域法
Abstract: The frequency characteristics of multilayered broadside, edge-coupled mul-timicrostrip llines are analyzed by using spectral domain immittance approach. The design curves about characteristic impedances and effective dielectric constants are given for three-layered broadside, edge-coupled microstrip lines. It is shown that the even-odd mode impedance changes rapidly with frequency, especially when the dielectric constant r is small. -
D. Pavlidis et al., IEEE Trans. on MTT, MTT-24(1976)10, 631-640.[2]A. Presser, IEEE Trans. on MTT, MTT-26(1978)10, 801-805.[3]S. Rehnmark, IEEE Trans. on MTT, MTT-26(1978)4, 225-231.[4]J. A. Allen, IEEE Trans. on MTT, MTT-22(1974)12, 1182-1186.[5]T. Itoh, IEEE Trans. on MTT, MTT-28(1980)7, 733-736.[6]S. K. Koul et al.,IEEE Trans. on MTT, MTT-30 (1982)11, 1874-1880.[7]T.Itoh et al., IEEE Trans. on MTT, MTT-22(1974)10, 896-898.[8]周文表,電子科學學刊,7(1985)2, 152-157.[9]S. A. Ivanov, IEEE Trans. on MTT, MTT-29(1981)6, 611-615. -
