迴旋自諧振脈塞的Bragg腔設計分析
DESIGN OF BRAGG CAVITY IN CYCLOTRON AUTORESONANCE MASER
-
摘要: 迴旋自諧振脈塞是一種工作在毫米、亞毫米波段、兆瓦級以上功率的相干輻射器.本文敘述了迴旋自諧振脈塞的基本原理,著重給出諧振系統Bragg腔的分析設計方法和計算結果.從皺紋波導理論出發,根據它的分布反射特性,推導出一個相關參數S.利用S參數結合實例可以較為簡捷地設計、選擇Bragg腔的工作模式.
-
關鍵詞:
- 迴旋自諧振脈塞; Bragg腔; 耦合波; 分布反射
Abstract: The cyclotron autoresonance maser (CARM) has been developed which is a high power device operating at short wavelength. In this paper, the basic principle of CARM is described, and the design method and numerical calculation results for Bragg cavity are shown. Based on the distributed reflection performance of the corrugated waveguide, an important parameters S is found with application of coupled-wave theory. S parameter is used simply to design a Bragg cavity and to select one of the operation modes. Finally some discussions are made. -
K. V. McCowan et al., lnt. J. Electron, 65(1988)3, 463-475.[2]R. B. McCowan et al., IEEE Trans. on ED, ED-36(1989)9, 1958-1974.[3]V. I. Bratman, G. G. Denisov, N. S. Ginzfurg, M. I. Petelin, IEEE, J. of QE,QE-19(1983)3, 282-296. -
