鰭線阻抗不連續性的混合模散射特性

洪嘉生,  孫林,  石俊明

洪嘉生, 孫林, 石俊明. 鰭線阻抗不連續性的混合模散射特性[J]. 電子與信息學報, 1990, 12(5): 488-496.
引用本文: 洪嘉生, 孫林, 石俊明. 鰭線阻抗不連續性的混合模散射特性[J]. 電子與信息學報, 1990, 12(5): 488-496.
Hong Jiasheng, Sun Lin, Shi Junming. HYBRID-MODE SCATTERING CHARACTERISTICS OF FINLINE IMPEDANCE DISCONTINUITIES[J]. Journal of Electronics & Information Technology, 1990, 12(5): 488-496.
Citation: Hong Jiasheng, Sun Lin, Shi Junming. HYBRID-MODE SCATTERING CHARACTERISTICS OF FINLINE IMPEDANCE DISCONTINUITIES[J]. Journal of Electronics & Information Technology, 1990, 12(5): 488-496.

鰭線阻抗不連續性的混合模散射特性

HYBRID-MODE SCATTERING CHARACTERISTICS OF FINLINE IMPEDANCE DISCONTINUITIES

  • 摘要: 本文用混合模展開鰭線中的本征場,并應用譜域法確定主模和高次模的傳播常數和譜域中的本征場,然后結合模匹配法分析鰭線阻抗不連續性的混合模散射特性。文中給出計算的單鰭前30個模,雙鰭前20個模的傳播常數和阻抗不連續性的主模散射參數,計算結果與文獻發表的結果一致。有關數值收斂性問題亦在文中進行了討論。
    Abstract: The eigenfields in finline are expanded in terms of the hybrid modes. The propagation constants of the dominant mode and the higer modes as well as the associated eigenfields in the spectral domain are then determined by using the spectral domain method. Finally the hybrid-mode scattering characteristics of finline impedance discontinuities are analysed in combination with the mode-matching technique. The propagation constants of the first 30 modes in unilateral finline and the first 20 modes in bilateral finline as well as the scattering parameters of the impedance discontinuities are computed. The computed results agree well with the published data. The problems about the numerical convergence are also discussed.
    • HTML全文
  • R.Sorrention, T. Itoh, IEEE Trans. on MTT,MTT-32(1984), 1633-1638.[2]K. J. Webb, R. Mittra, IEEE Trans. on MTT, MTT-33(1985), 1004-1010.[3]H. E1. Hennaway, K. Schuemann, Analysis of Finline Discontinuities, in Proc. 9th Eur. Microwave Conf. Brighton, England, (1979), pp. 448-452.[4]M. Helard et al., IEEE Trans. on MTT, MTT-33(1985), 994-1003.[5]T. Itoh, R. Mittra, IEEE Trans. on MTT, MTT-21(1973), 496-499.[6]A. S. Omar, K, Schunemann, Space Domain Decoupling of LSE and LSM Fields in Generalized Planar Guiding Structures, IEEE MTT-S Digest, 1984, pp. 59-61.[7]A. S. Oman K. Schuenmann, IEEE Trons. on MTT, MTT-33(1985), 1313-1322.
  • 加載中
計量
  • 文章訪問數:  2310
  • HTML全文瀏覽量:  135
  • PDF下載量:  521
  • 被引次數: 0
出版歷程
  • 收稿日期:  1989-02-10
  • 修回日期:  1989-12-19
  • 刊出日期:  1990-09-19
