手征介質偶極子天線研究
THE STUDY ON THE CHIRO-OMEGA DIPOLE ANTENNA
-
摘要: 本文首先探討了用手征介質作為微帶天線基片的可能性。應用廣義譜域指數矩陣方法,分析了單層和雙層手征介質中所有單元的三種不同取向?qū)ε紭O子天線輻射特性的影響,以及偶極子方向圖隨手征介質損耗正切的變化情況。
-
關鍵詞:
- 手征介質; 廣義譜域指數矩陣; 偶極子天線; 方向圖
Abstract: The possibility of using chiro-omega media as the substrates of microstrip antennas is discussed. With the help of the generalized spectral domain-exponential matrix technique, the far-field behaviour of dipole antenna is analysed in detail, which is located on the surface of one-layer, two-layer chiro-omega substrates, respectively, and the effects of the orientation of , chirality and -parameter on the radiation patterns are demonstrated. The lossy effect of chiro-omega substrates are also taken into consideration. -
Saadoun MMI, Engheta N. Micro[J].Opt. Tech. Lett.1992, 5(3):184-188[2]Saadoun MMI, Engheta N. Proc. URSI Radio Science Meeting, Ann Arbor, Michigan, USA: 1993, 304.[3]Lindell I V, et al. Micro[J].Opt. Tech. Lett.1993, 6(9):517-520[4]Tretyakov S A, et al. Micro[J].Opt. Tech. Lett.1993, 6(12):701-705[5]Tretyakov S A, Scohava A A. Electron. Lett., 1993, 29(12): 1048-1049.[6]Yin Wenyan, Wang Wenbing. Micro. Opt. Tech. Lett., 1994 7(10): 475-478.[7][7][8]Tsalamengas J L. IEEE Trans. on MTT., 1992, MTT-40(10): 1876-1879.[9]Tsalamengas J L. IEEE Trans. on AP., 1985, AP-33(2): 165-172. -
