螺旋線行波管大信號相互作用模型的改進
IMPROVEMENT ON THE LARGE SIGNAL INTERACTION MODEL FOR TWT
-
摘要: 由于Rowe模型的能量不守恒性,使它用于實際的行波管設計時,特別是相速躍變的螺旋線行波管的設計時會產生較大的誤差。本文提出的改進模型以能量守恒作為電子注和波之間的相互作用規范,所以在不計空間電荷力時,高頻場的功率和電子注消耗的功率精確相等。用新模型的計算結果比用Rowe模型的更接近實際情況,特別是在變相速的設計中。
-
關鍵詞:
Abstract: Because of the nonconservation of energy in Rowe s modei for large signal interaction in TWT, Rowe s modei produces considerable error in TWT design, especially for a velocity-tapered one, A modified model which is based on energy conservation is suggested to improve the accuracy of the design of TWT. By the new model, when the loss and space charge in TWT are neglected, the energy received by the circuit is exactly equal to that given by the electron beam. And all the results obtained with the new model a re in better agreement with the actual cases then those obtained with Rowe's model. -
J. E. Rowe, IRE Trans. on ED, ED-3 (1956), 39.[2]電子管設計手冊編委會,行波管非線性相互作用理論和計算,電子管設計手冊參考資料,1976, 7.[3]姜遵富等,科學通報,1978年,第1期,第31頁.[4]宋文淼,電子學通訊,2(1980), 119.[5]Otto Sau Seng, 7th MOGA. (1968), 16.[6]陳培龍,電子學通訊,1(1979), 64.[7]周文表,電子學通訊,2(1980), 72.[8]范崇澄,電子學通訊,1(1979), 74. -
