利用光電導開關的光電子相關測量
PHOTOELECTRON CORRELATION MEASUREMENT BY PHOTOCONDUCTIVE SWITCHES
-
摘要: 本文在實驗的基礎上,提出了光電導開關等效時變電導的新表達式。據此分析了光電導開關在高速脈沖的產生和取樣以及在光電子相關測量中的特性。分析的結果與實驗基本一致,為將來利用光電子相關方法測量電子器件打下了基礎。在實驗中采用較為簡單的工藝,獲得光電導開關的上升時間為100ps。相信,只要增加離子轟擊處理,上升時間可望達到10ps。Abstract: On the basis of experiments, a new conductive expression of photoconductive switch is proposed. According to this expression, the generation and sampling of high speed pulses, as well as the characteristics of photoelectron correlation measurement are analysed. The analysis agrees with experimental results and will be useful to the electronic measurement by photoelectron correlation method. A rather simple processing of devices is adopted. The rise time of photoconductive switch is 100 ps. It is sure that the rise time may obtain a ten-fold improvement only with ion-bombardment to the substrate.
-
D. H. Auston, P. R. Smith, Laser Focus,18(1982), 89-93.[2]D. H. Auston, et al., Appl. Phys. Lett.,37(1980), 371-373.[3]D, H. Auston, Appl. Phys. Lett., 26(1975), 101-103.[4]C. H. Lee, Appl.Phys. Lett., 30(1977), 84-86.[5]P. R. Smith, et al., Appl. Phys. Lett., 38(1981), 47-50. -
