任意E面膜片不連續性及其在毫米波濾波器中的應用
ARBITRARY E-PLANE STRIP DISCONTINUITIES AND THEIR APPLICATION TO MILLIMETER WAVE FILTERS
-
摘要: 本文利用矩量法和一般的網絡分析技術分析了各種E面膜片不連續性。通過引入廣義波導概念,自然地考慮了膜片的厚度效應,使問題的分析得到了統一。文中給出了一組正面膜片不連續性的等效電路參量曲線,基于這些曲線,設計和試制了二個W波段E面帶通濾波器,實驗結果與設計指標符合較好。
-
關鍵詞:
- 毫米波; 集成電路; 濾波器; 等效電路參量
Abstract: Various E-plane strip discontinuities are analyzed by the moment method and generalized network analysis technique. By introducing an idea of wide-sense waveguide, a united treatment of such problems is realized, and the thickness of the strip is taken into account. A set of curves for the equivalent circuit parameters of E-plane strip discontinuities are given. Two E-plane bandpass filters are designed and tested at W-band. Experimental results agree well with theoretical predictions. -
Y. Konishi, et al., IEEE Trans. on MTT, MTT-22(1974), 869-873.[2]李嗣范,陳憶元,中國科學A輯,1982年,第9期,第857-866頁.[3]F. Arandt, et al., IEEE Trans. on MTT, MTT-30(1982), 155-163.[4]Y. C. Shih, et al., IEEE Trans on MTT, MTT-31(1983), 135-142.[5]Rong Aosheng, Li Sifan, IEEE MTT-S Int Microwave Symp Digest, U. S. A., 1987, 721-724.[6]R. F. Harrington, Time Harmonic Electromagnetic Fields, New York, McGraw-Hill, 1961.[7]K. C. Gupta, et al., Computer-Aided Design of Microwave Circuits, Dedhan, MA, Artech House, 1981.[8]Li Sifan, Rong Aosheng, 12th Int. Conf. Infrared and Millimeter Waves, U. S. A., 1987, 251-252. -
