頻域Mur條件差分近似的構造和應用
FINITE-DIFFERENCE APPROXIMATIONS IN FREQUENCY-DOMAIN FOR MUR S CONDITIONS AND ITS APPLICATIONS
-
摘要: 本文構造了Mur條件的頻域有限差分近似。結合推導的非均勻、各向異性媒質中有限差分方程,可以有效、方便地計算電大尺寸復雜媒質體的電磁散射問題。運用稀疏矩陣壓縮存貯技術和迭代求解算法,大大減少了所占用的計算機內存,與矩量法相比計算時間也大為減少。文中計算了幾種媒質情況上圓柱和方柱的雷達散射截面,并與已有數據作了比較,結果一致性較好。
-
關鍵詞:
- 差分近似; Mur條件; 電磁散射; 有限差分法; 矩量法; 雷達散射截面
Abstract: Novel finite-difference approximations of Mur s conditions are presented in frequency-domain. Combined with the FD-FD equations deduced, the new conditions are convenient and effective to solve EM problems of inhomogeneous anisotropic media. By use of the compressed storage sparse matrix technique and iteration algorithm, the computer memories demanded are decreased and the CPU time is shortened compared with those obtained by moment method (MM). RCS of cylinders and rectangular posts are given with several kinds of media. The results of cylinder are in good agreement with those of MM. -
Mekewether D E. IEEE Trans. on EMC, 1971, EMC-13(1): 41-44.[2]Kunz K S, Lee K M. IEEE Trans. on EMC, 1978, EMC-20(2): 328-333.[3]Yee K S. IEEE Trans. on AP, 1966, AP-14(5): 302-307.[4]Taylor C D, Lam D H, Shumpert T H. IEEE Trans. on AP, 1969, AP-17(9): 585-589.[5]Taflove A, Brodwin M E. IEEE Trans. on MTT, 1975, MTT-23 (8): 623-630.[6]Mur G. IEEE Trans. on EMC, 1981, EMC-23(4): 377-382.[7]Canning F X. IEEE Trans. on AP, 1990, AP-38(5): 740-745.[8]Jin J M, Vohskis J L, Liepa V V. IEEE Trans. on AP, 1989, AP-37(1): 118-123.[9]Areadt S, Umashadcar K R, TaBove A, et al. IEEE Trans. on AP, 1989, AP-38(7): 1551-1558.[10]Jankovic D J, Chang D C, Dunn J M, et al. IEEE Trans. on AP, 1993, AP-42(9): 1215-1222.[11]Sun W, Balanis C A. IEEE Trans. on AP, 1993, AP-42(5): 627-632. -
