迴旋磁控管工作性能的初步分析
PRELIMINARY ANALYSES ON OPERATING CHARACTERISTICS OF GYROMAGNETRON
-
摘要: 本文從色散方程出發,導出了迴旋磁控管的小信號增益表達式。估算了電子效率。用計算機進行了計算,結果表明,在一定條件下,工作于6次諧波的8mm迴旋磁控管(f0=35GHz)的小信號增益可達2dB/cm,電子效率接近8％。這些結果為設計和改進迴旋磁控管的工作特性提供了一定的理論依據。此外,為了提高效率,還提出了磁控管波導型迴旋佩尼管的設想。
-
關鍵詞:
Abstract: Starting from the dispersion relationship of gyro magnetron, the expression of small-signal gain has been derived. The electronic efficiency is also estimated. The computing results show tha.t under defined conditions a gain per unit length of 2dB/cm and an electronic efficiency of nearly 8% a.t 35 GHz with 6th harmonie of the cyclotron frequency can be obtained. The computing results will be an useful information for design and improvement of gyro-magnetron. Moreover, the conceived gyro-peniotron with magnetron waveguide is proposed for efficiency enhancement. -
Y, Y. Lau and L. R. Barnett, Int. J. Infrared and Millimeter Waves, 3(1982), 619.[2]D. B. McDermott, N. C. Luhman, Jr., D. S. Foruno, A. Kupiszewski and H. R. Jory, ibid., 4(1983), 639.[3]P. Vittells, 9th Int. Conf. on Infrared and Millimeter Waves, Takarazuka, Japan, 1984, p. 162.[4]S. Ono, K. Tsutaki and T. Kageyama, IEDM Tech. Digest,(1983), p. 456.[5]K. R. Chu, A. T. Drobot, V. L,. Granastein and J. L. Seftor, IEEE Trans. on MTT, MTT-27(1979), 178.[6]K. R. Chu, A. T. Drobot, H. H. Szu and P. Sprangle, ibid.,MTT-28(1980), 313. -
