PIN調制器用于線性脈沖調制的可能性
POSSIBILITY OF USING THE PIN MODULATOR FOR LINEAR PULSE MODULATION
-
摘要: 本文分析了PIN調制器的電流調制特性,對其在線性坐標上呈現(xiàn)的高度非線性作了討論,并進一步提出了采用對數網絡使其線性化的電路補償方法,這種方法在實驗中已獲得成功。
-
關鍵詞:
Abstract: The current modulation characteristic of PIN modulator is analyzed, and its highly-nonlinear characteristic appearing on a linear coordinate is discussed. A circuit com-pensation method, in which a logarithmic network is mainly used, is presented for making the modulator linearized. This method shows up satisfactorily in experiment. -
The application group, Hewlett-Packard LTD. Electronic Components, 7(1966), 59.[2]顧其凈,項家禎,袁孝康,微波集成電路設計,人民郵電出版社,1978年,第611頁. -
