用MBPE快速計算三維導體RCS的頻空特性
Applications of MBPE for RCS Fast Calculation of 3D PEC Objects
-
摘要: 該文系統研究了MBPE技術求解三維理想導體雷達散射截面(RCS)的寬頻帶特性。通過把電流在感興趣的頻率點處采用泰勒級數或者Pade有理函數展開，來獲得理想導體某頻帶范圍內的電流，從而可求出寬帶雷達散射截面。同時，該文還將有理逼近應用于RCS的空域和頻域雙內插。數值結果表明MBPE技術獲得的結果與確切解在寬頻帶、大角度范圍內吻合良好，計算效率大大提高。
-
關鍵詞:
- MBPE; 雷達散射截面; Pad有理函數
Abstract: An implementation of the Model Based Parameter Estimation(MBPE) tech-nique is presented for obtaining the RCS frequency response of arbitrarily shaped Perfect Electric Conductor (PEC) bodies. The electric current is expanded in a Taylor series or Pade rational function around the frequency of interest, thus the -scattering field is obtained over the bandwidth. Rational function fitting model is also used for the interpolation of RCS in both spatial domain and frequency domain. A good agreement can be seen between MBPE and the exact solution, and the computational burden is significantly reduced. -
Reddy C J. Application of model based parameter estimation for RCS frequency response calculations using method of moments. NASA/CR-1998-206951.[2]Rao S M, Wilton D R, Glisson A W. Electromagnetic scattering by surfaces of arbitrary shape.IEEE Trans. on AP, 1982, AP-30(3): 409-418.[3]Reddy C J. Application of AWE for RCS frequency response calculations using method of moments. NASA Contractor Report 4758, October 1996.Cockrell C R, Beck F B. Asymptotic Waveform Evaluation(AWE) technique for frequency domain electromagnetic analysis. NASA Technical Memorandum 110292, November 1996.[4]Werner D H, Allard R J. The simultaneous interpolation of antenna radiation patterns in both the spatial and frequency domains using modal-based parameter estimation. IEEE Trans. on AP., 2000, AP-48(3): 383-392. -
