一種合成孔徑雷達對地面運動目標成像和精確定位的算法
An Effective Method for Ground Moving Target Imaging and Location in SAR System
-
摘要: 該文針對正側視合成孔徑雷達工作體制下運動目標成像、定位問題進行研究。分析了運動目標成像與靜止目標成像的異同。提出利用距離歷程擬合,結合靜物場景成像的部分已知信息(地面道路或者橋梁的方向),準確估計t=0時刻目標的坐標和兩維速度,不僅為運動目標精確成像提供了信息,同時得到目標運動軌跡相對地面場景的準確位置。該文提出的方法對于目標在照射孔徑內的位置沒有特殊假設(以往研究的時頻分析方法需要假設目標在t=0時刻位于載機的正側方向)。最后定量分析了不同形式匹配濾波器對運動目標回波成像的效果以及采用靜止目標匹配濾波器對運動目標回波進行成像處理而產生的移位和散焦影響.Abstract: This paper addresses the research of ground moving target imaging and posi-tioning in Synthetic Aperture Radar (SAR) system. First it analyzes the difference between ground moving target imaging process and that for stationary ones. The method brought forward in this paper uses the direction of road and bridge of the gazing ground as prior known knowledge, and it can accurately estimate the coordinates and velocities of the moving targets while t = 0. It means that the method can get the position of the moving targets and image them with the same precision as stationary targets imaging in SAR system. There is no special postulation in the proposed algorithm contrast to the conventional method which always assumes that the targets located on the vertical side of SAR at the point of t = 0. Finally two different forms of matched filters are given out for moving targets imaging and the different results are analyzed. The smearing and position shifting effect when using sta-tionary target matched filter to process the moving target echo is also analyzed at the last part.
-
Klemm R. Space-Time Adaptive Processing Principles and Application. UK: Short Run Press Ltd., 1998: 1-10, 64-84.[2]Ender J, Klemm R. Airborne MTI via digital filtering. IEE Proc.-Radar, Sonar and Navigation,1989, 136(1): 22-28.[3]Barbarossa S, et al.. Space-time-frequency processing of synthetic aperture radar signals. IEEE Trans. on AES, 1994, 30(2): 341-358.[4]Blacknell D, et al.. Geometric accuracy in airborne SAR images. IEEE Trans. on AES, 1989,25(2): 241-258.[5]Coe D J, White R G. Moving target detection in SAR imagery: experimental results. IEEE Int.Radar CNF, Alexandria, VA, USA, 1995: 644-649.[6]Soumekh M. Moving target detection and imaging using an X band along-track mono-pulse SAR.IEEE Trans. on AES, 2002, 38(1): 315-333.[7]Moccia A, Rufino G. Space-borne along-track SAR interferometry: performance analysis and mission scenarios. IEEE Trans. on AES, 2001, 37(1): 199-213. -
