超寬帶多注速調管的模擬研究
Theoretical Investigations of the Super Broadband Multiple Beam Klystron Amplifier
-
摘要: 本文介紹了多注速調管的發展歷史和現狀，以及速調管模擬軟件的發展情況。用1.5維軟件Klystron -MSU和2.5維軟件Arsenal-MSU對超寬帶多注速調管進行了設計計算，并對計算結果進行分析，得到了比較好的輸出特性。計算結果表明可以實現該超寬帶多注速調管，其帶寬10~14%，增益40~50dB，效率40~50%。Abstract: The development, the computer simulations of klystron and design of super broadband multiple beam klystron are introduced in this paper. It shows some results of simulation of super broadband MBK by 1.5D code Klystron-MSU and 2.5D code Arsenal-MSU. Theoretical investigations of simulation results are described in details. The results show an opportunity of realization the multiple beam klystron with bandwidth about 10～14 %, gain 40～50 dB at electronic efficiency about 40~50 %.
-
Gelvich E A, Borisov L M, Zhary E V, Zakurdayev A D, Pobedonostzev A S, Pugnin V I. The new generation of high power multiple-beam klystron[J].IEEE Trans. on MTT.1993, 41(1):15-[3]Pohl W J. The design and demonstration of a wide band multiple-beam traveling wave klystron[J].IRE Trans. on ED.1965, 12(6):351-[10]Ding Y G, Rodjakin V E, Sandalov A N. Features of development and creation broadband klystron amplifiers. Proc. of VIII All-Russia a School-Seminar, Physics and Application of microwaves, Zvenigorod, May 26-30 2001, vol.1, 74.75. -
