聲光頻譜分析器的信號處理
THE DATA PROCESSING TECHNIQUE OF THE IOAOSA
-
摘要: 集成光學聲光頻譜分析器是由半導體激光器、導波聲光調制器、波導短程透鏡和CCD探測器陣列所構成。CCD探測器把接收的光信號轉換成電信號,再由TMS32010系統與IBM-PC機組成的主從工作機的信號處理中心進行處理。微機系統中的CPU采用TMS-32010。CCD視頻信號采集用循環間隔采樣方式。此樣機達到的指標:系統帶寬為100MHz,分辨率為8MHz,動態范圍為20dB。
-
關鍵詞:
- 信號處理; 聲光頻譜分析器; CCD探測器陣列
Abstract: An IOAOSA (Integrated Optical Acoustooptic Spectrum Analyzer) system consists of semiconductor laser, acoustooptic modulator, geodesic lenses, and CCD detector array. The optical signal is converted to electrical signal by CCD array of the IOAOSA processor, and then the signal is processed by the signal processing center which consists of TMS32010 system and IBM-PC. The TMS32010 is used in the microcomputer system. It has very high speed. A cyclic sample method is used to collect the data of the CCD video signal, sampling one point every 40 points. After processing, the frequency bandwidth. the resolution and the dynamic range of the system are measured to be 100MHz, 8MHz and 20dB respectively. -
M. K. Barnoski, Bor-Uei Chen et al., IEEE Trans. on CAS, CAS-26(1979) 12, 1113-1124.[2]J. W.顧德門, Fourier光學導論,科學出版社,北京,1979年,第五章,第二節.[3]中國科學院聲學所中國軟件技術開發部, TMS32010 數字信號處理器軟件和硬件開發技術,1987年5月. -
