三維矢量散射分析中奇異積分的準確計算方法
THE ACCURATE INTEGRATION METHOD OF SINGULARITY INTEGRATION FOR THREE DIMENSIONAL VECTOR FIELD SCATTERING
-
摘要: 在用積分方程和矩量法(MM)或快速多極子法(FMM)分析三維矢量散射時,都要對有奇異性的被積函數進行積分。如果直接使用高斯積分,則準確性很低。為了得到準確的積分結果,本文在分析了高斯積分原理的基礎上提出了積分區域分割法。此方法將積分區域劃分為一個包含奇異點的部分和若干個無奇異點的部分。對無奇異點的部分可直接用高斯積分求解,而對包含奇異點的部分,則可通過簡化被積函數,變量代換和加減同階奇異項等方法獲得它的解析表達式。本文將這種方法用到電場積分方程(EFIE)的矩量法中,以角反射器和導電球目標散射特性(RCS)為例,其計算的結果與文獻非常吻合。
-
關鍵詞:
- 高斯積分; 奇異性; 積分區域分割法
Abstract: When three dimensional vector scattering is analyzed by integral equation and the moment method(MM)or the fast multipole method(FMM)，the singular integrand will be done，If it is calculated by Gaussian integration directly,the accuracy will be very poor.In order to get an accurate result，this paper provides a method of integral domain division,which divides the integral domain into several parts with one of them containing the singularity.In the singular part,an analytic result can be derived by simplifying the integral function,replacing the variables,of adding and subtracing a sinlar term．The other can be calculated by Gaussion integration directly.Numerical results for RCS of a corner-reflector antenna and a conducting sphere calculated by this method are in reasonable agereement with that in the references． -
Song J M，Chew W C. Moment method solutions using parametric geometry,Journal of Electro magnetic Waves and Application,1995,9(1/2)：71-83．[2]Newiman E H．Polygonal plate modeling,Electromagnetics,1990,10(1):65-83.[3]武漢大學，山東大學計算數學教研室編.計算方法.北京：高等教育出版，1992：170-173.[4]梅向明，黃敬之編 微分幾何．北京：人民教育出版社，1981：98-104．[5]Wang N N，Richmond J H,Gilreath M C.Sinusoidal reaction formulation for radiation and scattering from conducing surfaces.IEEE Trans.on AP，1975,AP-23(3):376-382.[6]Deng S H，Chew W C,et al.Solving some surface integral equation by using MOM with curved trangular patches. Digest of the 1997 Radio Science Meeting,Atlanta:1997,1818-1821. -
