基于非零散度關系的交替方向隱式減縮FDTD算法
An Algorithm of ADI-FDTD and R-FDTD Based on Non-zero Divergence Relationship
-
摘要: 該文證明了即使在無源區域，交替方向隱式時域有限差分法(ADI-FDTD)所給出的電磁場量不滿足零散度關系，同時推導出了該散度關系的具體表達式。基于該非零散度關系，將不受Courant穩定條件限制的ADI-FDTD法和能節約最多達1/3內存的減縮時域有限差分(R-FDTD)法結合，提出了一種新的交替方向隱式減縮FDTD算法。該算法保留了ADI-FDTD能增大時間步長，縮短計算時間的優點，同時與ADI-FDTD相比節約了最多達1/3(三維)或2/5(二維)的內存。與基于零散度關系的ADI/R-FDTD相比，該算法避免了采用長時間步長計算時的發散現象。應用所提出的ADI/R-FDTD算法計算了二維自由空間波的傳播及一維頻率選擇表面垂直入射的問題，計算結果與ADI-FDTD計算結果完全一致，驗證了ADI/R-FDTD的正確性和有效性。
-
關鍵詞:
- FDTD;減縮時域有限差分法(R-FDTD);交替方向隱式(ADI)技術
Abstract: In this paper, it is proven that the divergence relationship of electric-field and magnetic-field is non-zero even in charge-free regions, when the electric-field and magnetic-field are calculated with Alternating Direction Implicit Finite-Difference Time-Domain (ADI-FDTD) method, and the concrete expression of the divergence relationship is derived. Based on the non-zero divergence relationship, the ADI-FDTD which is unconditionally stable is combined with the Reduced Finite-Difference Time-Domain(R-FDTD). In the proposed method (ADI/R-FDTD), the merit of ADI-FDTD, e.g. increasing time step size and decreasing calculation time, is kept, at the same time, the memory requirement is reduced by 1/3(3-D) or 2/5(2-D) of the memory requirement of ADI-FDTD. Compare to the ADI/R-FDTD based on regular zero divergence relationship, the proposed algorithm is more stable when lager time step size is used. Wave propagation in 2-D free space and the scattered field of a 1-D Frequency Selective Surface(FSS) is simulated by the proposed hybrid method. Compared with ADI-FDTD，perfect agreement of numerical results indicates that ADI/R-FDTD method is correct and efficient. -
Namiki T. A new FDTD algorithm based on alternating direction implicit method [J]. IEEE Trans. on Microwave Theory and Techniques, 1999, 47(10): 20032007 .[2]Zheng F, Chen Z, Zhang J. Toward the development of a three-dimensional unconditionally stable Finite-Difference Time-Domain method [J]. IEEE Trans. on Microwave Theory and Techniques, 2000, 48(9): 19501958. .[3]George D K, Franco D F, Gregory J O, et al.. A memory-efficient formulation of the Finite-Difference Time-Domain method for the solution of Maxwell equation [J].IEEE Trans. on Microwave Theory and Techniques.2001, 49(7):1310-[4]周永剛，徐金平. 減縮時域有限差分法在電磁干擾預測中的應用[J]. 東南大學學報，2003, 33(4): 392.395.[5]Liu Bo.[J].Gao Benqing, Tan Wei, Ren Wu. A new FDTD algorithm ADI/R-FDTD. 2002 3rd International Symposium onElectromagnetic Compatibility, Beijing, China.2002,:-[6]Tsay Wen-Jiunn, Pozar D M. Application of the FDTD technique to periodic problems in scattering and radiation [J].IEEE Microwave and Guided Wave Letters.1993, 3(8):250- -
