有限厚度襯底非對稱共面線的基本參數
BASIC PARAMETERS OF ASYMMETRICAL COPLANAR LINES WITH FINITE SUBSTRATE THICKNESS
-
摘要: 本文首先利用保角變換法分析了自由空間中的非對稱共面線,得到了其嚴格解,然后給出了任意多層有限厚度襯底非對稱共面線的有效介電常數、單位長度線電容、特性阻抗和導波波長的閉合形式的解析表達式。這些分析對微波毫米波集成電路的設計有意義。
-
關鍵詞:
- 共面線; 非對稱; 有效介電常數; 特性阻抗; 導波波長
Abstract: In this paper, asymmetrical coplanar lines in free space are analyzed using confor-mal mapping techniques, and the exact solutions are obtained. Analytic closed-form expressions for the effective dielectric constant, the capacitance per unit length, the characteristic impedance and the wavelength of guided wave for asymmetrical coplanar lines with multi-layered finite substrate thickness are obtained. The analyses are useful for the (M)MIC s designs. -
Kneppo I, Gotzman J. Basic parameters of nonsymmetrical coplanar lines. IEEE Trans. on MTT, 1977, MTT-25(8): 718.[2]Gevorgian S S. Asymmetric coplanar-strip transmission lines for MMIC and integrated optic applications[J].Electron. Lett.1990, 26(22):1916-1917[3]Cohn S S. Slot line on a dielectric substrate. IEEE Trans. on MTT, 1969, MTT-17(5):768-778.[4]Wen C P. Coplanar waveguide: A surface strip transmission lines suitable for nonreciprocal gyromagnetic device. IEEE Trans. on MTT, 1969, MTT-17(6):1087-1090.[5]Veyres C, Hanna V F. Extension of the application of conformal mapping techniques to coplanar lines with finite dimensions. Int. J. Electron.1980, 48(1): 47-56.[6]Hanna V F. Finite boundary corrections to coplanar stripline analysis[J].Electron. Lett.1980, 16(15):604-606[7]Gevorgian S S. Basic characteristics of two layered substrate coplanar waveguides[J].Electron. Lett.1994, 30(15):1236-1237[8]Bedair S S. Characteristics of some asymmetrical coupled transmission lines. IEEE Trarvs. on MTT, 1984, MTT-32(1):108-110. -
