基于魯棒穩定的閉環激磁電源幅值回路設計
The design for magnitude loop of the excitation power supply with closed-loop control based on robust stability
-
摘要: 保證系統魯棒穩定,同時滿足系統性能指標要求始終是控制設計的目標。該文根據轉臺測角系統對激磁電源穩定性和性能指標的要求,提出了采用H優化控制理論,以魯棒穩定為基礎的閉環激磁電源幅值回路設計的方法,討論了H控制器的求解過程。經四個轉臺長期使用驗證該設計方法的有效性和合理性,完全滿足了高精度轉臺的需要。
-
關鍵詞:
- 魯棒穩定; 性能; 閉環控制; 激磁電源
Abstract: It is always the goal of the control systems design that ensuring the system robust stability and satisfying the requirements of the system performance specifications at the same time. In this paper, based on the requirements of stability and performance specifications of the excitation power supply for the angular measurement system of test turntable, a design method, is presented, in which the robust stability based H-optimal control theory is applied to the magnitude loop of excitation power supply with closed-loop control. The solving process of the H controller is discussed. Long period of operation of the four test turntables has proven that the validity and rationality of the design method fully satisfy the requirements of high precision test turntable. -
陸永平,感應同步器及其系統,北京,國防工業出版社,1986,34-189.[2]馬智周,王作光,童力松,模塊化精密角度測量系統靜態和動態精度的分析,航空精密制造技術,1991,(5),28-31.[3]陳平,羅晶,王毅,王廣雄,蘇寶庫,反饋控制感應同步器雙相激磁電源研究,中國慣性技術學報,1997,5(1),53-56[4]J. C. Doyle, G. Stein, Multivariable feedback design concepts for a classical/modern synthesis,IEEE Trans. on Automatic Control, 1981, 26(1), 4-16.[5]B.A. Francis, G. Zames, On H-optimal sensitivity theory for SISO feedback system, IEEETrans. on Automatic Control, 1984, 29(1), 9-16.[6]J. C. Doyle, K. Glover, P. Khargonekar, B. A. Francis, State-space solutions to standard H2 andH control problems. IEEE Trans, on Automatic Control, 1989, 34(8), 831-847.[7]H. Kwakernaak, Robust control and H-optimization-tutorial paper, Automatica, 1993, 29(2),255- 273.[8]L. Petter, S. Sigurd, W. Zi-Q, Performance weight selection for H and -control methods.Trans. of Inst. of Measurement and Control 1991, 13(5), 241-252 .[9]曾鳴,精密伺服轉臺的幾個設計問題研究,[博士學位論文],哈爾濱工業大學,1999,54-92. -
