對稱三值電流型CMOS施密特電路

沈繼忠; 姚茂群

對稱三值電流型CMOS施密特電路

沈繼忠^{①;姚茂群},
姚茂群

計量
- 文章訪問數: 2329
- HTML全文瀏覽量: 178
- PDF下載量: 397
- 被引次數: 0
出版歷程
- 收稿日期: 1997-07-02
- 修回日期: 1998-02-15
- 刊出日期: 1999-03-19

SYMMETRIC TERNARY CURRENT-MODE CMOS SCHMITT CIRCUITS

Shen Jizhong^{①;姚茂群},
Yao Maoqun

摘要

摘要: 本文根據對稱傳輸電流開關理論,設計了可具有多個輸出的對稱三值電流型CMOS施密特反相器。計算機模擬結果表明,它具有理想的施密特特性,并可根據需要調整回差。
- 三值施密特電路; 電流型CMOS電路; 對稱三值邏輯
Abstract: By applying symmetric transmission current-switch theory, the symmetric ternary current-mode CMOS Schmitt inverter which can have multiple outputs is proposed, and its width of hystersis can be adjusted as needed. The result of computer simulation shows that the designed Schmitt inverter has nearly ideal Schmitt function.
