基于線性與或門的新型超高速數字電路
THE NEW SUPER-HIGH-SPEED DIGITAL CIRCUIT BASED ON LINEAR AND-OR GATES
-
摘要: 本文指出了線性與或門與發射極功能邏輯(EFL)的聯系,通過理論計算與PSPICE模擬證明了線性與或門的極高速工作特性和可多級級聯工作能力。在對線性與或門所需配用的高速開關分析基礎上,設計了兩種ECL電路。本文還討論了應用線性與或門設計超高速數字電路的準則以及有關的組合和時序電路設計實例。
-
關鍵詞:
- 線性與或門; 超高速數字電路; 多元邏輯電路
Abstract: The paper reveals the relation between linear AND-OR gate and the Emitter Function Logic (EFL). With theoretic calculation and PSPICE simulation, the paper proves that the linear AND-OR gates can work at super-high-speed and can be multi-cascaded. On the basis of analyzing the high-speed switch units which coordinate with linear AND-OR gates, two kinds of Emitter Coupled Logic (ECL) circuits are designed. The paper also discusses the design principle of super-high-speed digital circuits and some examples of combinational and sequential circuits using linear AND-OR gate are given. -
王守覺,等.電子學報,1987,6(2): 43-51.[2]王守覺,等.電子學報,1983,11(5): 9-16.[3]Skokan I E. IEEEJ. of SC, 1973, SC-8(5): 356-361.[4]Elmasry M 1. Digital Dipolar Integrated Circuits. New York: John Wiley Sons, Inc., 1989, Ch.6.[5]石寅.連續邏輯高速門陣列研究:[博士論文].北京:中國科學院半導體研究所,1986.[6]Muroga S. VLSI System Design. New York: John WileySons, Inc, 1982, Ch. 3.[7]Xunwei Wu(吳訓威),Zhuan Zhang(章專).Int. J[J].Electron.1991, 71(6):1023-1035[8]王守覺,石寅,朱榮華.半導體學報,1987,8(5): 466-473.[9]馮宏娟.DYL電路的研究新進展.中國第一屆多值邏輯電路與系統學術會議.青島:1991. -
