脈沖磁控管用H形阻抗變換器的設計
THE DESIGN OF H SHAPE IMPEDANCE TRANSFORMER FOR PULSED MAGNETRON
-
摘要: 本文簡要地?cái)⑹隽薍形阻抗變換器的設計方法,重點討論了H形波導的截止波長應如何正確選擇,才能使在調諧頻率范圍內磁控管的輸出功率比較均勻。最后進行了裝管熱測,結果與予期目標較符合。
-
關鍵詞:
- 磁控管; 脈沖磁控管; 阻抗變換器
Abstract: A design method of H shape impedance transformer is described briefly, and how to determine the cutoff wavelength is discussed, in order to decrease the difference of power output within the operational bandwith of magnetron. At last some tubes are mounred and tested. The results are satisfactory. -
電子管設計手冊編委會,磁控管設計手冊,國防工業出版,1979年,第148-154頁.[2]G. B. Collins, Microwave Magnetron, Radiation Laboratory Series, 1948, pp. 486-498.[3]張本良,電子管技術,1976年,第1期,第3-12頁.[4]科瓦連科著,吳鴻適,謝希仁譯,超高頻電子學引論,科學出版社,1957年,第4-11頁. -
