分層同軸介質諧振器諧振頻率特性的研究
STUDY OF RESONANT FREQUENCY CHARACTERISTIC OF DIELECTRIC COAXIAL RESONATORS
-
摘要: 本文導出了置于無限平行導體板間和置于屏蔽結構中的任意分層同軸介質諧振器的TE、TM模場分量表達式以及求解TE、TM模諧振頻率的一般耦合特征方程。對于同軸(l=3層)介質諧振器進行了深入研究和大量計算,得到了同軸(l=3層)介質諧振器的主模和一些高次模的諧振頻率隨幾何尺寸和介質特性變化的關系曲線和數據表。
-
關鍵詞:
- 同軸介質諧振器; 諧振頻率; 耦合特征方程
Abstract: The TE and TM mode field expressions and their general coupled characteristic equations of the dielectric coaxial resonators (any number of interfaces) placed between two parallel conducting plates or placed in shield are derived. Particularly, the dielectric coaxial resonator (three interfaces) is studied and calculated in detail. And curves and tables of dominant mode and some higher-order modes resonant frequencies varied with the resonantor geometry and dielectric properties are given. -
M, Pospieszalki, IEEE Trans. on MTT, MTT-25(1977), 228-231.[2]S. Fiedzuiszko, A. Jelenski, IEEE Trans. on MTT, MTT-19(1971), 778.[3]T. Itch, R. Rudokas, IEEE Trans. on MTT, MTT-25(1977), 52-54.[4]R. Devote, J. F. Toth, R. Caldecott, J. Appl. phys., 44(1973), 4488-4500.[5]R. D. Smedt, IEEE Trans. on MTT, MTT-32(1984), 1288-1293.[6]D. Maystre, P. Vincent, J. C. Mage, IEEE Trans. on MTT, MTT-31(1983), 844-848.[7]A. Julien, P. Guillon, IEEE Trans. on MTT, MTT-34(1986), 723-729.[8]陳進光, 張白熔, 電子學報, 1986年, 第5期, 第97-103頁. -
