準光腔單微帶貼片輸入阻抗的理論分析
AN ANALYSIS ON INPUT IMPEDANCE OF A SINGLE MICROSTRIP PATCH IN THE QUASI-OPTICAL CAVITY
-
摘要: 本文利用并矢格林函數獲得了準光腔中的電磁場積分方程。利用矩量法導出了被一個軸向電流源激勵的單微帶貼片腔的輸入阻抗的計算公式。利用本方法對矩形微帶貼片的輸入阻抗進行了討論。其結果與微帶天線很類似。這對設計微帶型準光振蕩器有重要的參考價值。
-
關鍵詞:
- 振蕩器; 準光腔; 輸入阻抗; 微帶貼片; 矩量法
Abstract: The electromagnetic field integral equation in the quasi-optical cavity is obtained using the dyadic Green s function. An expression is derived for the input impedance of a single microstrip patch cavity excited by a coaxial probe using method of moment. The input impedance of a rectangular microstrip patch is discussed by this method. The result of this paper is similar to that of the microstrip antenna. There is very important value for designing microstrip quasi-optical oscillator. -
A. Mortuzawi, T. Itoh, A Periodic Second Harmonic Spatial Power Combining Oscillator, 1990 IEEE MTT-S Digest, pp, 1213-1216.[2]P,C. Frayne, C,J.Riddaway, Electron. Lett., 24(1988)16, 1017-1018.[3]R.A. York, R.C. Compton, IEEE. Trans. on MTT, MTT-39(1991)6, 1000-1009.[4]M.D. Ieshpande, M.C. Bailey, IEEE Trans, on AP, AP-30(1982)7, 645-650.[5]Yijun He, Quanrang Yang, The Dyadic Green's Function in the Open Cayity, July 1992, IEEE[6]ISAP,Chicago, USA.[7]P.K. Yu, A.L. Cullen, Proc.R. Soc. Lond. A, 380(1982), 49-71.[8]王一平,陳達章,劉鵬程,工程電動力學,西北電訊工程學院出版社,西安.1985年. -
