頻率和極化復用的群分波器的準確設計
EXACT DESIGN OF A WIDE-BAND WAVEGUIDE DUPLEXING FILTER
-
摘要: 本文利用等效電路的概念,在求解了波導接頭的邊界值問題后,給出了4GHz、6GHz頻率和極化復用饋線系統中群分波器的準確設計方法。計算結果與實測相符。此方法可用于同類型其它結構的分波器設計。
-
關鍵詞:
Abstract: After solving the boundary value problem of a waveguide junction, the exact design method of a wide-band duplexing filter for 4 and 6 GHz relay communication is obtained by using the concept of equivalent circuit. The theoretical results are in good agreement with the measured data. This design method can be used for other wide-band duplexer with similar construction. -
P. Marie, Onde Electrique, 39(1959), 189-194.[2]K. Schnetzler, Nachrichten Technische Zeitschrift, 22(1969)3, 144-145.[3]加藤修助,研究實用化報告,3(1970), 581-587.[4]小口文一,マイクロ波ぉよびミリ波回路,丸善株式會社,1964.[5]Sharp, IEEE Trans. on MTT, MTT-15(1967), 109-116.[6]G. Simpson, A generalized n-port cascade connection, 1981 Int. Microwave Symposium Digest, pp. 507-510. -
