平行板偏轉系統的幾何象差和優化設計
GEOMETRIC ABERRATIONS AND OPTIMUM DESIGN OF AN ELECTROSTATIC DEFLECTION SYSTEM CONSISTING OF PARALLEL PLANAR CONDENSERS
-
摘要: 本文從理想均勻靜電場偏轉系統三級幾何象差的公式出發,導出了由兩對互相垂直的偏轉板組成的平行平板偏轉系統的三級幾何象差公式。這些公式不但可用來快速估算偏轉象差,還可用來作為校驗數字計算程序的理論模型。從水平和垂直方向偏轉象散和場曲的影響應相同這一要求出發,提出了一種優化設計方法。在給定偏轉區總長度和兩對偏轉板之間的距離后,可以計算出每對偏轉板的最佳長度。文中給出了設計數表,并比較了平行平板偏轉系統和八極偏轉系統的優缺點。
-
關鍵詞:
- 靜電偏轉; 幾何象差; 優化設計
Abstract: Formulae of the third order geometric aberrations caused by the pirallcl planar deflection systems consisting of two planar deflectors disposed sequentially and orthogonally have been derived. These formulae can be used as an analytic solution for quickly estimating the geometric aberrations of a known deflection system and checking the related computer program. In view of attaining minimum and equal deflection aberration on the horizontal and vertical sides of a square scanning area, a method of optimum design is proposed. When the total length of the deflection region and the distance between the two deflectors are given, the optimum length of each of the two deflectors can be calculated by this method. -
R. D. Moore, G. A. Caccoma, H. C. Pfeiffer, et al., A High Throughput, High Resolution e-Beam Litho-[2]graphy Tool, Proc. of the 16th Symp. on Electron, Ion and Photon Beam Technology, Dallas, Taxas, May 26-29, 1981, pp. 950-952.[3]J. Kelly, T. Groves, H. P, Kuo, A High-Current, High Speed Electron Beam Lithography Column, Proc. of the 16th Symp. on Electron, Ion, and Photon Beam Technology, Dallas, Taxas, May 26-29, pp.936-[4]940.[5]G, Cogswell, S. Mlyauchi, K. Tanaka, N. Goto, Electron Beam Lithography System with variable-Speed Electron Beam, Proe. 8th Int. Symp. Electron and Ion Beam Soci. Technol., Beijing, 1978, pp. 117-133.[6]江鈞基, 電子科學學刊, 8(986), 359-366. -
