硅低溫雙極晶體管的數值模擬
NUMERICAL SIMULATION OF LOW-TEMPERATURE BIPOLAR TRANSISTOR
-
摘要: 本文討論了有關低溫雙極器件模擬物理參數的低溫模型和各種低溫物理效應,確立了適用于低溫雙極器件模擬的數值分析方法,建立了適用于77-300K溫度范圍內硅雙極器件模擬程序,最后模擬分析了一典型結構品體管的常溫和低溫時的工作特性。
-
關鍵詞:
- 雙極晶體管; 器件模擬; 低溫; 優化設計
Abstract: Numerical models for the physical parameters and physical effects about numerical simulation of low-temperature bipolar transistor are discussed. The numerical approaches required for simulation of low-temperature behavior are presented. A simulation program has been given to investigate bipolar transistor behavior range of 77-300K. Finally, the characteristics of a typical bipolar transistor are simulated at 300K and 77K. -
鄭茳.硅低溫雙極品體管的理論與優化設計:[博士論文],南京:東南大學,1994.5.[2]Blaudau W, Onton A Heinke W. Temperature dependence of the bandgap of silicon[J].J. Appl. Phys.1974, 45(4):1846-1848[3]Wagner J, et al. Band-gap narrowing in heavily doped silicon: A comparison of optical and[4]electrical data. J. Appl. Phys，1988, 63(2): 425-433.[5]Slotboom W, H. C. De Graaff. Measurement of bandgap narrowing in silicon bipolar transistors. Solid-State Electronics, 1976, 19(10): 857-862.[6]Chen Y W, et al. Two-dimensional analysis of a BiNMOS transistor operating at 77K using a[7]modified PISCES program. IEEE Trans. on Electron Devices, 1992, ED-39(2): 348-356.[8]Selberherr S. MOS device modeling at 77K. IEEE Trans. on Electron Devices, 1989, ED-36(9): 1464-1476.[9]Ghazavi P, Ho F D.A numerical model for MOSFETs from liquid-nitrogen temperate to room temperate. IEEE Trans. on Electron Device, 1995, ED-42(1): 123-131.[10]Chen Y W, James B K. Two-dimensional analysis of a Binmos transistor operating at 77K using[11]a modified PISCES program. IEEE Trans. on Electron Devices, 1992, ED-39(2): 348-357. -
