摘要:
本文介紹了S波段200kW多注寬帶速調管的研究工作。給出了多注速調管及其電子光學和聚焦系統、寬帶輸出電路的設計和計算結果。并給出了我國第一批實驗型多注寬帶速調管的性能:工作電壓19kV時,控制極負偏壓為7kV,脈沖電流32.25A,導流系數12.3P,電子注直流通過率91.8％。最大輸出功率252kW,平均功率3.5kW,效率41％,增益49dB,帶寬9.1％,帶內功率波動1.7dB。
Abstract:
Multi-beam klystron (MBK) is a new type of high power microwave amplifier. The S-band multi-beam broadband klystron doveloped in Institute of Electronics of Academia Sinica (IEAS) is described in this paper. The research progresses on the design and calculation of the tube, multi-beam electron gun and focusing system, broadband output circuit are given. For beam voltage of 19kV and bias voltage of control electrode of --7kV, the measured performance of the tube are as follows: the beam current of 32.25A, beam perveance of 12.3P, DC beam transmission of 91.8, peak power of 252kW, average power of 3.5kW, the efficiency of 41, the gain of 49dB, the band width of 9.1 with 1.7dB power variation.
