多注速調管一種新型大功率微波放大器
MULTIBEAM KLYSTRON-A NEW TYPE OF HIGH POWER MICROWAVE AMPLIFIER
-
摘要: 本文介紹了一種新型大功率微波放大器多注速調管。扼要地評述了多注速調管的發展概況,詳細地介紹了基于速調管諧振腔基模的多注速調管的工作原理和主要特點。研究了多注速調管參數對工作帶寬和輸出功率的影響。給出了多注速調管的功率限制。指出了多注速調管的關鍵技術問題和發展趨勢。
-
關鍵詞:
- 多注速調管; 導流系數; 諧振腔基模
Abstract: A new type of high power microwave-multibeam klystron has been described. The development of multibeam klystron is commented on briefly, the principle and main characteristics of multibeam klystron based on the fundamental mode of klystron cavity are given in detail. The effect of the parameters of multibeam klystron on the operating bandwidth and output power has also bean studied, and the power limitation is given in this paper. Finally, the key technical problems and trend of multibeam klystron are pointed out. -
Kovalenko V F.[J].Anthers Certificate, No. 72756, Class 21, 13, Applied on Dec.1940,31:-[2]Bernier J, Patent No. 992853, Sept. 15, 1944, dance.[3]Boyd bf R, et al.,IRE Trans. on ED, 1962, ED-9(3): 247.[4]Pohl VW J, et al.,IRE Trans. nn ED, 1965, ED-12(6): 351-368.[5]Branch G M, et al., AD-807 515/2, AD-812 190/7, AD-815 777/8, Sept. 1966-March 1967.[6]Gelvich E A, et al., IEEE Trans. on MTT, 1993, MTT-41(1): 15-19.[7]Pobedonostsev A S, 1993 IEEE MTT-S, Digest, 1993, 1131-1134.[8]Gelvich E A, et al., 1991 IEEE MTT-S, Digest, 1991, 1319-1329.[9]Faillon G, Technical Digest of IEDM, 1986, 784-786.[10]Bearzatto C, et al., ITG-Fachbericht, No. 120, 1992, 45-51.[11]Reod D W. 1988 Linear Accelerator Conference, 1988, 514-518.[12]Mourier G, European Patent EP O 440530 Al, 1991, 1-11.Mourier G, European Patent EP O 440529 Al, 1991, 1-13. -
