高溫超導微波電路襯底材料復介電常數的測量
MEASUREMENT OF COMPLEX PERMITTIVITY OF MIC SUBSTRATES FOR DEPOSITION OF HTS THIN FILMS
-
摘要: 本文討論了在液氮溫度下高溫超導微波電路介質襯底材料復介電常數測試技術。利用TMono模高Q圓柱形諧振腔,對高溫超導常用的幾種單晶介質材料進行了測試。結果表明,該測試技術在不同溫度下,可對低耗單晶和各向同性介質材料進行準確的測試,且測試簡便、迅速、自動化程度高,具有測試介質材料某一方向復介電常數的優點。
-
關鍵詞:
- 諧振腔; 單晶介質材料; 復介電常數; 微波測量
Abstract: A technique is analysed for the determination of complex permittivity of MIC substrates for deposition of high- superconducting (HTS) thin films. By using high Q factor TM circular cavity, several monocrystals which are often used for deposition of HTS thin films are measured. The results show that the technique covers accurate measurements of the low-loww monocrystal and isotropy dielectric materials at different temperature, and the test is simple, rapid and automatic, and some directional complex permittivity of the dielectric materials can be measured. -
Wu M K, et al. Phys[J].Rev. Lett.1987, 58(5):908-910[2]Konopka J, et al. Dielectric Properties of Substrates for Deposition of High-Tc Thin Films up to[3]GHz, 1992 Applied Superconductivity Conference. Chicago:Aug. 1992.[4]Sobolewski R,et al. IEEE Trans. on MAG, 1991, MAG-27(2): 876-879.[5]Konapka J, et al. J[J].Appl. Phys.1992, 72(1):218-223[6]R. A 瓦爾特朗著,徐鯉庭譯.被導電磁波原理.北京:人民郵電出版社,1977,第五章. -
