螺旋線行波管速度再同步的理論和計算(三)
THEORY AND CALCULATION OF VELOCITY RESYNCHRONISM FOR HELIX TWT (3)
-
摘要: 本文用螺旋線行波管通用大信號計算程序分析研究了Rowe與Sauseng兩類提高效率的方法,找出了他們的共同之點。同時從理論上研究了單級相速跳變行波管的電子效率與跳變量的關系,并求出了最佳跳變段長度。結果得到了實驗的證實,為具體管子的設計提供了理論依據。
-
關鍵詞:
Abstract: This paper analyzes two kinds of method which can raise the efficiency of TWT by using universal helix TWT program. The relationship between the electronic efficiency of TWT with the single phase velocity jump and the magnitude of the velocity jump is evaluated and the optimum length of the velocity jump is given theoretically. These theoretical results are in agreement with the experimental ones and can be used in design of actual TWT. -
J. G. Meeker and J. E. Rowe, IRE Trans. on ED, ED-9(1962), 257.[2]J. E. Rowe et al., IEEE Trans. on ED, ED-12(1965), 441.[3]O. Sauseng, 7th International Conference on Microwave and Optical Generation and Amplification. (1968), p. 16-29.[4]陳培龍,電子學通訊,1(1979), 64.[5]周文表等,電子學通訊,3(1981), 222.[6]周文表,螺旋線行波管通用大信號計算程序,中國科學院電子所內部報告,1979年. -
