扇調管一種新型高效率微波管
SECMOTRON--A NEW KIND OF HIGH EFFICIENT MICROWAVE TUBE
-
摘要: 扇調管(扇形電子束偏轉調制管)是在偏調管(gyrocon)基礎上發展起來的一種高效率微波管。木文分析了偏調管的基本原理及其限制,指出改善偏調管的性能必須提高其線路效率。本文論述了提高導流系數是其關鍵之一,從而引出了扇形束的設想以減弱空間電荷效應,并提出了使普通圓柱形電子束變成扁平的扇形束的基本概念和結構。最后給出了對具體結構進行數值計算的結果,表明以上設想是可行的。Abstract: Secmotron (Sector beam deflection modulation tube) is a new kind of high efficient microwave tube which is developed on the basis of gyrocon. The principle of gyrocon has been analyzed and it manifests that to increase circuit efficiency is necessary for improving properties of a gyrocon. One of the key points is to increase its perveance. An idea about sector beam is proposed to reduce the effect of space charge. Also the concept and construction of transforming a column beam into a thin sector beam are presented. The numercal calculation of some specific structures demonstrates that above idea is realizable.
-
J. W. Mcrae, Harmonic Generaeian System, US Patent, 2408437, Oct, 1946.[2]I. Kaufman, G. Oltman, IEEE Trans. on ED, ED-12(1965), 31-39.[3]G. I. Budker, et al., Particle Accelerators, 10(1979), 41-59.[4]P. J. Tallerico, et al., IEEE Trans. on ED, ED-26(1979)10, 1559-1566.[5]P. J. Tallerico, IEEE Trans. on NS, NS-30(1983)4, Pt. 2, p. 3420.[6]Zheng Weiping, Li Shengpei, Proceedings of Second Asia-Pasific Microwave Conference, Beijing, 1988, PP. 370-371. -
