合成孔徑雷達用的垂直極化天線
A VERTICAL POLARIZED ANTENNA FOR SYNTHETIC APERTURE RADAR
-
摘要: 正 (一)引言 合成孔徑雷達是成象雷達。它對測繪地區的地物目標進行成象。通常,雷達天線只輻射水平極化的電磁波,但由于地物目標的多樣性和復雜性,往往對電磁波的極化有轉換效應。為了使雷達盡可能多地收集地物目標的遙感信息,只作一種極化的發射和接收顯然是不夠的。為此,我們?cè)谘兄戚椛渌綐O化波的天線的基礎上研制了輻射垂直極化波的天線,提供給雷達樣機作飛行試驗成象和圖象比較用。 設計垂直極化天線采用的是波導隙縫線陣和喇叭形結構的方案。它的外形、尺寸和
-
關鍵詞:
Abstract: This paper describes a simple design method of a vertical polarized antenna operated in the X-Band. This antenna consists of longitudinal shunt slotted array at the broad side of rectangular waveguide and metallic horned plates.A real size model was fabricated. The eomputed results are in agreement with measured ones approximately. Although this method is preliminary, it has practical value in antenna design. -
W. H. Watson, The Physical Principles of Wave Guide Transmission and Antenna Systems, Chapter 8,(1946).[2]Г.З.Айизенберг,Антенны Улътракоротких Волн Главы Ⅸ,Ⅺ,ⅩⅫ,Связъиздат Москва,1957.[3]田憲祖,電子科學學刊,5(1983), 192.[4]A. E. Ratkevich, Meteorological Radar Facility (MRF) Slot Conductance Investigations, NASA CR-152465. January, 1977. -
