蒙特卡羅-牛頓法進行電路產品合格率估計和最優中心設計
MCA-NEWTON METHOD FOR CIRCUIT YIELD ESTIMATION AND OPTIMIZATION
-
摘要: 本文利用蒙特卡羅法估計電路產品合格率對元件參數中心值的一、二階偏導數,再與牛頓最優化方法結合得到了一個電路中心設計的算法,為了提高偏導數估計值的精度,文中又給出了利用失敗樣本點的估計式。為了減少電路分析次數,作者提出了適用于蒙特卡羅分析的采樣頻率按權排序法,理論分析和算例表明:本文算法是成功的,適用于非凸、非單連通可行域,可進行中等規模電路的產品合格率估計和中心設計。
-
關鍵詞:
Abstract: An algorithm for circuit yield estimation and optimization is described. To obtain the first and second derivatives of yield with respect to center and get the optimal circuit center, the Monte Carlo analysis and Newton method are employed. By using fail samples and rearranging sample frequencies according to their weights, two new methods for improving estimation and reducing computation are presented. Both theoretical analysis and calculation examples show that this algorithm performs well and can be used for middle-scale circuit design. No matter the region of acceptability is convex set or not, the algorithm is available. -
R.K. Brayton, et al.,Proc. IEEE, 69(1981), 1334.[2]K.Singghal and J. F. Piney IEEE Trans. on CAS, CAS-28(1981), 692.[3]D. E. Hocevar, et al., ibid, CAS-30(1983 ), 180.[4]D. M. Himmelbiau著,張文燊等譯,實用非線性規劃,科學出版社,1983.[5]于驍勇,電子電路優化設計的一個算法,中國電子學會CAS學會第五屆年會論文集(西安),1989,pp 364-8.[6]E. Wehrhahn and R. Spence, IEEE Proc. ISCAS84, pp. 1424-38.[7]R. S. Soin and R. Spence, IEE Proc., pt. G, 127 (1980) , 260.[8]D. Agnew, and P. E. Men, ibid., 127(1980). 270.[9]M. A. Styblinski, et al., IEEE Proc. ISCAS81, pp. 554-7.[10]K. S. Tahim and R. Spence, IEEE Trans. on CAS, CAS-26(1979), 768.[11]于驍勇,重慶大學碩士論文,1985. -
