三腔分離腔的結構尺寸對頻率的影響
The effect of the dimensions of split cavity with three cavities on its resonant frequency
-
摘要: 該文從圓柱坐標系下的Borgnis位函數的齊次標量Helmholtz方程出發,引入慢波駐波概念及其場表達式,利用Borgnis位函數的邊界條件及相鄰子區公共界面上的場匹配條件,導出了三腔分離腔內角向均勻TM模的色散關系,并利用色散關系分析了三腔分離腔的結構尺寸對諧振頻率的影響。
-
關鍵詞:
- 分離腔; 色散關系; 諧振頻率
Abstract: Starting from homogeneous scalar Helmholtzs equations associated with Borgnis potential function in a cylindrical coordinate system, and based on the standing wave concept of slow-wave introduced in the paper, the analytic expressions of the dispersion relation for azimuthally symmetric transverse magnetic modes in the split cavity with three cavities are derived, by using boundary conditions for Borgnis potential function in conjunction with field matching conditions at the common interface between the adjacent subregions. Besides, the effect of the high frequency structure dimensions of split cavity with three cavities on its resonant frequency is analyzed in detail. -
B.M.Marder et al.,IEEE Trans.on Pisa.Sci.1992,PS-20(3),312-331.[2]R.W.Lemke,J.Appl.Phys.,1992,72(9),4422-4428.[3]D.A.Watkins,Topics in Electromagnetic Theory,New York,Wiley,1958,1-10. ［4］張克潛,李德杰,微波與光電子學中的電磁理論,北京,電子工業出版社,1994,259-260[4]劉盛綱,微波電子學導論,北京,國防工業出版社,1985,672.[5]范植開,渡越管振蕩器的理論研究與原理性實驗[博士學位論文],北京,中國工程物理研究院北京研究生部,1999.62[6]陳森玉,高能物理與核物理,1982,6(5),546-554.[7]范植開,劉慶想,物理學報,2000,49(7),1249-1255. -
