吉赫橫電磁波傳輸室傳輸特性的寬頻帶分析

季飛,  張國基,  崔芙蓉,  賴聲禮

季飛, 張國基, 崔芙蓉, 賴聲禮. 吉赫橫電磁波傳輸室傳輸特性的寬頻帶分析[J]. 電子與信息學報, 2000, 22(6): 1022-1027.
引用本文: 季飛, 張國基, 崔芙蓉, 賴聲禮. 吉赫橫電磁波傳輸室傳輸特性的寬頻帶分析[J]. 電子與信息學報, 2000, 22(6): 1022-1027.
Ji Fei, Zhang Guoji, Cui Furong, Lai Shengli. WIDE BAND ANALYSIS OF TRANSMISION CHARACTERISTICS IN GTEM CELL[J]. Journal of Electronics & Information Technology, 2000, 22(6): 1022-1027.
Citation: Ji Fei, Zhang Guoji, Cui Furong, Lai Shengli. WIDE BAND ANALYSIS OF TRANSMISION CHARACTERISTICS IN GTEM CELL[J]. Journal of Electronics & Information Technology, 2000, 22(6): 1022-1027.

吉赫橫電磁波傳輸室傳輸特性的寬頻帶分析

WIDE BAND ANALYSIS OF TRANSMISION CHARACTERISTICS IN GTEM CELL

  • 摘要: 吉赫橫電磁波傳輸室(GTEMcell)上限工作頻率可達幾個吉赫，因而在電磁兼容測量中得到越來越廣泛的重視和應用。本文在非正交坐標系下采用FDTD(時域有限差分)法求解電磁波在GTEMcell中的傳輸特性，給出了GTEMcell中TEM模的橫向分布和縱向分布，分析了高階模對場分布均勻性的影響，由此確定了GTEMcell的上限工作頻率范圍。計算及分析結果對GTEMcell的設計和使用具有重要意義。
    Abstract: The TEM cell is limited in the upper useful test frequency but GHz TEM (GTEM) cell permits to overcome this restriction. This paper analyzes the transmisssion characteristics in GTEM cell using FDTD method in the nonorthogonal coordinate. The field distributions have been calculated and the upper useful frequency has been analyzed. The results are of great value to the using and designing of GTEM cells.
    • HTML全文
  • Crawford Myron L. Generation of standard EM fields using TEM transmission cells[J].IEEE Trans.on Electromagn. Compat.1974, EMC-16(4):189-195[2]Spiegel R J, Joines W T, Blackman C F, Wood A W. A method for calculating electric and magnetic fields in TEM cells at ELF. IEEE Trans. on Electromagn. Compat., 1997, EMC-29(4):265-272.[3]Koenigstein D, Hansen D. A new family of TEM-cells with enlarged bandwidth and optimized working volume, In Proc. 7th Int. Zurich Symp. And Techn. Exh. on EMC, Zurich: 1987,127-132.[4]De Leo R, Rozzi T, Svara C, et al. Rigorous analysis of the GTEM cell. IEEE Trans. on Microwave Theory and Tech., 1991, MTT-39(3): 488-499.[5]Liu Y, Tang B, Gao Y. Sphere-TEM mode in rectangular top horn offset coaxial transmission line. IEEE Trans. on Electromagn. Compat., 1994, EMC-36(4): 390-394.[6]Kama Huang, Yongqin Liu. A simple method for calculating electric and magnetic fields in GTEM cell. IEEE Trans. on Electromagn. Compat., 1994, EMC-36(4): 355-358.[7]Holland R. Finite-difference solution of Maxwells equations in generalized nonorthogonal coordinates. IEEE Trans. on Nucl. Sci., 1983, NS-30(6): 4589-4595.[8]Jinfa Lee, Palandech R, Mittra R. Modeling three-dimensional discontinuities in waveguides using nonorthogonal FDTD algorithm. IEEE Trans. on Microwave Theory and Tech., 1992, MTT-40(2): 346-352.[9]Holland R, Williams J W. Total-field versus scattered-field finite-difference codes: A comparative assessment. IEEE Trans. on Nucl. Sci., 1983, NS-30(6): 4583-4588.[10]Berenger J P. A perfectly matched layer for the absorption of electromagnetic waves[J].J. Comput. Phys.1994, 114(2):185-200
  • 加載中
計量
  • 文章訪問數:  2448
  • HTML全文瀏覽量:  120
  • PDF下載量:  447
  • 被引次數: 0
出版歷程
  • 收稿日期:  1999-02-03
  • 修回日期:  1999-08-22
  • 刊出日期:  2000-11-19
