多層環狀導電媒質中離軸偶極子輻射場的級數解
SERIES SOLUTION OF THE ELECTROMAGNETIC FIELD EXCITED BY AN OFF-AXIS DIPOLE IN CIRCULARLY MULTILAYERED MEDIUM
-
摘要: 當偶極子源(電偶極子或磁偶極子)置于多層環狀導電媒質中偏離軸線的任意一點時,所激發的電磁場既存在TE波又存在TM波。文中導出了各層媒質中電磁場的通解,用邊界條件建立了系數傳遞矩陣,從而完全確定了電磁場表達式。計算實例中給出了一組離軸偶極子的響應曲線。
-
關鍵詞:
- 多層環狀媒質; 電偶極子; 磁偶極子; TE波; TM波
Abstract: When a dipole source(electric dipole or magnetic dipole) is located at arbitrary point in circularly multilayered conductive medium,the electromagnetic fields excited by the source contain both TE and TM waves.The series solutions of the fields in very layer are derived analytically in this paper.A coefficient recurrence matrix is established by means of the boundary conditions.In such way,the expressions of fields can be degermined definitely.As a numerical example,a group of response curves of an off-axis source are given finally. -
Gianzero S, Anderson B. Mathematical theory for the fields due to a finite a. c. coil in an infinite thick bed with an arbitrary number of co-axial layers. The Log Analyst, 1984, 25(2): 25-32.[2]Wait J R. General formulation of the induction logging problem for concentric layers about the borehoke. IEEE Trans. on Geoscience and Remote Sensing, 1984, GR-22(3): 34-42.[3]Chew W C. Waves and Fields in Inhomogeneous Media. Nen York: Van Nostrand Reinhokd 1990, 70-79.[4]徐建華編著.層狀媒質中的電磁場與電磁波.北京:石油工業出版社,1997, 96-126.[5]張善杰,唐漢.任意實數階復宗量第一類和第二類Bessel函數的精確解.電子學報,1996, 24(3): 77-81. -
