1GHz裂環諧振腔的設計和制作
DESIGN AND MANUFACTURE OF 1GHz SPLIT RING RESONATOR
-
摘要: 本文用等效電路的方法,推導了腔的諧振頻率及Q值表達式,并用螺線管的磁場等效腔的磁場,進一步得出了Q值與腔的尺寸、屏蔽殼及耦合環之間的關系。用計算機作出了關系曲線,從曲線可以得到腔的最佳設計方案。 在1到1.4GHz頻率范圍內的實驗表明:Q值容易達到900～1000。這種腔具有結構簡單、體積小、調諧范圍寬及Q值高等優點。
-
關鍵詞:
Abstract: In this paper, relationship between the Q value and the resonant frequency is derived by means of equivalent circuit method. The parameters are obtained by taking the cavity cylinder as a helical circuit. A series of curves for optimum design is plotted.In our experiment, a high Q value of 900 to 1000 in the frequency range of 1 to 1.4 GHz is easily obtained, the resonator has the merits of small dimension, wide frequency range and simplicity in construction. -
M. Giordano. F. Momo and A. Sotgin. J. Phys. E: Scientific Instrumentsm 16(1983), 774.[2]W.N. Hardy and L. A. Whitehead, Rev. Sci. Instrum., 52(1981), 213.[3]P. Momo, A. Sotgin and R. Zonta, J. Phys. E: Scientific Instruments, 16(1983), 43.[4]E. M. Purcell著,南開大學物理系譯,伯克利物理教程,第二卷,科學出版社,1979年,第254頁.[5]M. Wind and H. Rapart著,吳培享等譯,微波測量方法,上?？茖W(xué)出版社,1964,第230頁. -
