帶平臺多階振幅量化的低副瓣口徑分布
LOW SIDELOBE APERTURE DISTRIBUTION OF MULTI-STEP AMPLITUDE QUANTIZATION WITH PEDESTAL
-
摘要: 本文提出了一種帶平臺多階振幅量化的低副瓣口徑設計方法并論述了其分析方法和計算公式,給出了本文算法與作者(1993)提出的多階振幅量化方法在峰值副瓣電平、口徑效率、歸一化輸入功率以及具有容差情況下的副瓣惡化等的計算比較結果。結果表明,在相同的條件下,本文提出的方法優于多階振幅量化方法。
-
關鍵詞:
- 低副瓣; 口徑分布; 帶平臺多階振幅量化; 口徑效率; 副瓣惡化; 容差
Abstract: A low sidelobe aperture designing method of multi-step amplitude quantization with pedestal is proposed, and general analysis and formulas are described. The computation results compared with author s(1993) previous method Multi-Step Amplitude Quantization (MSAQ) on peak sidelobe level, aperture efficiency, normalized input power and sidelobe degradation with tolerance are given. It is shown that, in the same conditions, the method presented in this paper is better than the MSAQ. -
Skolnik M. IEEE Trans. on AP, 1964, AP-12(7):408-417.[2]Goo Y C. IEE Proc. -H, 1983, 130(5): 343-351.[3]Guo Y C. IEE Proc.-H, 1983, 130(5):352-357.[4]Guo Y C. The amplitude quantization of density-weighted phased array antenna. Proc. of 1985[5]Int. Symp. on Antenna and EM Theory. Beijing: 1985, 667-671.[6]陳紅,等.武漢大學學報(電波傳播專刊),1991,167-171.[7]Guo Y C. Analysis and computation of circular aperture arrays with multi-step amplitude quantization, 1992 IEEE AP-S Int. Symp. and URSI Radio Science Meeting. Chicago: 1992, 473-[8]476.[9]Lee J J. IEEE Trans. on AP, 1988, AP-36(3):339-344.[10]Gao Tie, Design of AEW 2-D Solid-State Active Phased Array Antennas with Low SideIobe[11]Level. The Third International Symposium on Antenna and EM Theory. Nanjing: 1993, 545-548.[12]高鐵,李建新.中國空間科學技術,1993,13(3): 34-42.[13]李建新,高鐵.現代雷達,1992,14(6): 37-44.[14]Li J X, Gao T. Pattern Statistic Characteristic Research for Low Sidelobe Solid-State Active Phase Array Antenna. 1993 Asia-Pacific Microwave Conference. Taiwan: 1993, 21-24. -
